P. 123
工程设计
ENGINEERING DESIGN
加载 100 万个循环,试验过程中观察空气弹簧泄漏情 气弹簧扭摆试验要求,水平剪切位移增加,扭摆刚度
况、橡胶止口磨损情况。 变小,垂向载荷对扭摆刚度影响不明显。
3.3.2 结果及分析
100 万次疲劳试验后空气弹簧未出现漏气现象, 参考文献 :
[1] 林达文,王进,轨道车辆橡胶弹性元件可靠性试验台,机车
橡胶止口无磨损,试验过程中试验机无异常和振动现
电传动,2012 年第 3 期: 74-76.
象,试验结果一方面表明空气弹簧具有较好的扭摆疲 [2] 林达文,彭立群,隔震橡胶支座力学性能试验研究,铁道建筑,
劳性能,另一方面表试验机结构设计合理,满足空气 2014 年第 2 期: 30-32.
弹簧扭摆刚度和疲劳试验要求。 [3] 林达文,彭立群,轨道客车空气弹簧振动试验台的设计及应
用研究,机车电传动,2015 年第 3 期: 86-89.
[4] 林达文,彭立群,轨道客车空气弹簧扭转试验台的设计及应
4 结束语 用研究,机车电传动,2016 年第 4 期: 96-98.
(1)分析了空气弹簧结构及标准,设计了一种新 [5] 林达文,彭立群,风机齿轮箱弹性支撑试验台的研制及应用,
特种橡胶制品,2017(4): 45-49.
型的空气弹簧扭摆试验装置,并与现有空气弹簧扭摆
[6] 林达文,彭立群,高铁桥梁液压阻尼器性能试验研究,铁道
试验装置进行分析比对,试验设计为空气弹簧的研发 技术监督,2021 年第 6 期: 27-31.
和试验起指导作用。 [7] 王进,谭帅霞,林达文,轨道交通橡胶弹性元件配方分析和
性能试验技术 [M]. 北京 :中国铁道出版社,2013.
(2)结果表明 :新型试验设计结构合理,满足空
Design and research of rubber air spring torsion performance
test device
Lin Dawen , Peng Liqun , Huang Tao , Wang Jin 1,2*
1,2
1,2
1,2
(1.Zhuzhou Times New Material Technology Co. LTD., Zhuzhou 412007, Hunan, China;
2. Hunan Rail Transit Polymer Materials and Products Quality Supervision and Inspection Center, Zhuzhou
412007, Hunan, China)
Abstract: This article studies the torsional stiffness and fatigue characteristics of rubber air springs. Firstly,
an in-depth analysis was conducted on the structure and related standards of air springs. On this basis, a
new type of air spring torsion pendulum test device is designed and compared with the existing test device.
Through a new experimental device, the influence of different horizontal shear displacements and vertical
loads on torsional performance, as well as the influence of different loading cycles on fatigue performance,
were mainly explored. The research results indicate that the structural design of the new experimental device
is reasonable and fully meets the requirements of the air spring torsion pendulum test. As the horizontal shear
displacement increases, the torsional stiffness shows a decreasing trend, while the effect of vertical load
on torsional stiffness is not significant. This research provides theoretical guidance for the development and
testing of air springs.
Key words: air spring; torsional performance; experimental study
(R-03)
2025 第 51 卷 ·75·
